Enphase EN-B05-C01-US00-1-3 - (1) 5kW LFP Battery Unit - Cover Sold Separately

Enphase IQ Battery 5P (B05-C01-US00-1-3) | 5.0 kWh Unit

The IQ Battery 5P is Enphase’s highest-performing 5.0 kWh AC-coupled storage solution. This SKU includes one (1) 5.0 kWh battery unit and one (1) mounting bracket.

• Note: This unit is sold WITHOUT the ID cover. The cover must be ordered separately (SKU: EN-B10C-NC-0708-O or B05-C-0550-O depending on your configuration).

Performance Highlights:

• Instantaneous Response: New wired communication system for high-speed, reliable backup.
• 3.84 kVA Continuous Power: Delivers nearly double the output capacity of previous 5kWh generations.
• 15-Year Warranty: Industry-leading limited warranty for long-term home energy security.
• Chemistry: Lithium Iron Phosphate (LFP) for maximum safety and durability.

Technical Specifications:

• Rated (continuous) output power: 7.08 kVA
• Rated output current (@240 V_L-L AC~): 29.5 A
• Rated neutral current (@120 V_L-N AC~): 24 A
• Interconnection: Single-phase
• Nominal voltage: 120/240 VAC~
• Nominal frequency: 60 Hz
• Usable capacity: 10.0 kWh
• Ambient operating temperature range (charging): −20°C to 50°C (−4°F to 122°F), Non-condensing
• Ambient operating temperature range (discharging): −20°C to 55°C (−4°F to 131°F), Non-condensing
• Chemistry: Lithium iron phosphate (LFP)
• Mounting: Wall-mount or pedestal-mount (sold separately)
